615
In case of an emergency
Description Fuse rating Protected component
GLOW PLUG 80A Glow plug
PTC HEATER #1 50A PTC heater 1
PTC HEATER #2 50A PTC heater 2
PTC HEATER #3 50A PTC heater 3
FUEL FILTER HEATER 30A Fuel filter heater
Engine compartment fuse panel (Diesel only)
Description Fuse rating Protected component
ALT 125A/150A (DIESEL) Alternator
MDPS 80A MDPS control module
ABS 2 20A Anti-lock brake system
ABS 1 40A Anti-lock brake system
B+.1 50A In panel B+
RR HTD 40A Outside rearview mirror defroster
BLOWER 40A Blower
C/FAN 40A Condenser fan
B+.2 50A In panel B+
IGN 2 40A Ignition switch
IGN 1 30A Ignition switch
ECU 30A Engine control unit
SPARE.1 20A Spare fuse
FR FOG 15A Fog light relay (front)
A/CON 10A Air conditioner relay
HAZARD 15A Hazard warning light
F/PUMP 15A Fuel pump relay
ECU.1 10A Engine control unit
ECU.3 10A Engine control unit
ECU.4 20A Engine control unit
INJ 15A Air conditioner relay, Injector
SNSR.2 10A Sensors
HORN 15A Horn relay
ABS 10A Anti-lock brake system
Description Fuse rating Protected component
ECU.2 10A Condenser, Ignition coil
B/UP 10A Back-up light
H/LP LO-RH 10A Headlight (low beam-right)
H/LP LO-LH 10A Headlight (low-left)
H/LP HI 20A Headlight relay (high beam)
SNSR.1 10A Oxygen sensor
SPARE 10A spare fuse
SPARE 15A spare fuse
SPARE 20A spare fuse
Engine compartment fuse panel
