Smartra immobilizer (2.5D E/G)
Diagnostic trouble codes and associated procedures
1.
Locate the data link connector (DLC) in the engine compartment and install the Hi-Scan Pro Tool.
2. Turn the ignition switch to ON and record any Diagnostic Trouble Codes displayed by Hi-Scan Pro
Tool.
3.
Refer to Diagnostic Trouble Code Chart, for fault description and actions.
4.
MIL(Malfunction indicator lamp) does not illuminate
DIAGNOSTIC TROUBLE CODE (DTC) CHART (2.5D E/G)
Diagnostic Trouble
Code
Fault Description
P1609
Immobilizer fault
a.
Immo. Line fault
b.
Invalid tester request
c.
EEPROM faulty - non plausible VSP data.
d.
Transponder fault
e.
Smartra fault.
f.
Authentication not successful.
g.
EEPROM fault for KEY ID block & IMMO data block
P1633
Immobilizer status lamp fault
a.
Short circuit line
b.
Open circuit line OFF
GENERAL DIAGNOSTICS AND TEST
SYSTEM CHECK
Step
Action
Normal results
1
a.
Observe "IMMO" indicator.
b.
Turn the ignition switch to ON.
"IMMO" indicator illuminates for approximately 30
seconds and goes out.
2
a. Turn the ignition switch to OFF and
START.
Engine starts.
3
a. Perform limp home with original correct
user password.
"IMMO" indicator illuminates for approximately 30
seconds and goes out.
4
a.
Turn the ignition switch to START.
Engine starts.
IMMOBILIZER SYSTEM
DIAGNOSTIC TROUBLE CODES
