ASSEMBLY INSTRUCTIONS
5
5.
Insert 60-watt max. Edison bulb (included)
into socket (E).
4.
Pass fixture (A) over the long machine screws
(DD) protruding from the mounting bracket
(B) and secure in place with threaded knobs
(CC).
3.
Mounting surface should be clean, dry, flat
and 1/4 in. larger than the fixture (A) on all
sides. Any gaps between the mounting
surface and fixture (A) exceeding 3/16 in.
should be corrected as required with silicone
caulking compound (not included). Caulk
completely around where back of fixture (A)
meets the wall surface to prevent water from
seeping into outlet box.
x 2
CC
Threaded
Knob
Hardware Used
CC
A
DD
B
4
5
E
3
A
To Next Page
