Assembly Instructions
1. ATTACH SIDE PANEL P1 TO END PANEL P2 WITH BOLT H1 AND WASHER H2.SEE FIGURE 1.
2. SLIDE THE FOOT BALL & HOCKEY PLAYING FIELD P3 INTO THE GROOVE ON THE SIDE PANEL P1 AND
END PANEL P2 .SEE FIGURE 2.
3. ATTACH SIDE PANEL P1 TO END PANEL P2 WITH BOLT H1 AND WASHER H2.SEE FIGURE 3.
1
2
P2
P3
P1
P2
H2
H1
3
H2
H1
