KICK Duo - Attach Handles and Rod End Caps; Attach Scorer

KICKFoosballTables.com I (866)-844-KICK (5425) I support@kickfoosballtables.com
7
Assembly Instructions
5. SLIDE THE HANDLES P5 ON THE ENDS OF THE RODS .SEE FIGURE 11.
ATTACH THE HANDLES P5 ON THE ENDS OF THE RODS WITH SCREW C4.SEE FIGURE 12.
SLIDE THE ROD END CAPS P6 ON THE OTHER END OF THE ROD .SEE FIGURE 13.
6. ATTACH SCORER P4 TO END PANEL WITH SCREW H3.SEE FIGURE 15-16.
15
16
P4
12
P6
11
14
P5
13
P5
C4
P4
H3
H3
