KICK Galaxy - Final Touches: Handles and Scorers

KICKFoosballTables.com I (866)-844-KICK (5425) I support@kickfoosballtables.com
10
Assembly Instructions
18. SLIDE THE HANDLES P15 ON THE ENDS OF THE RODS .SEE FIGURE 27.
ATTACH THE HANDLES P15 ON THE ENDS OF THE RODS WITH SCREW H12.SEE FIGURE 28.
19. ATTACH SCORER P16 AND P17 TO END PANEL WITH SCREW H13.SEE FIGURE 30-32.
29
30
31
27
28
P15
32
H13
P17
H13
P17
H13
P16
H12
P16
