4
8. Install the white three pin power connector on the subwoofer power wire. Close the retainer.
Fig. 7
9. Connect the subwoofer power wire to the subwoofer harness. Fig. 8
10. If equipped with power seats, adjust the passenger seat as high as possible. Remove the panel
next to the seat. Fig. 9
11. Remove the front kick/sill trim panel as well as the rear sill panel. Fig. 10
12. Connect the ground wire to the ground point
located in the right front kick panel area. Fig.
11 Tighten to 7.5Nm (66in-lb)
Fig. 11
Fig. 8
Fig. 9 Fig. 10
Then close
retainer
Insert terminals first. Any
wire can be in any position.
Fig. 7
