10English
Sealed Enclosures
These sealed enclosure designs give the
smoothest response with increased energy
at the lowest frequencies, 20 to 30Hz.
These designs deliver massive amounts of
highly-accurate bass and can be driven with
punishing levels of amplifier power.
The CompQ-Series high performance
suspension system can operate in a larger
sealed enclosure. This maximum enclosure
volume application is ideal for SQ (ultra
sound quality) installations. The Maximum
enclosure generates a very flat response
curve and extends the sub-bass response.
Minimum Sealed
Model Volume ft
3
(L) Min/Max Power
Handling
CWQ10 .66 (18.7) 400–800
CWQ12 .88 (24.92) 500–1000
CWQ15 1.5 (42.5) 600–1200
Model Volume ft
3
(L) Min/Max Power
Handling
CWQ10 1.25 (35.4) 400–800
CWQ12 2 (56.64) 500–1000
CWQ15 6 (169.9) 600–1200
Maximum Sealed
