6English
Series Wiring
COIL 1 COIL 2
Parallel Wiring
Dual 2Ω Voice Coils = 4Ω Load
Dual 4Ω Voice Coils = 8Ω Load
Dual 2Ω Voice Coils = 1Ω Load
Dual 4Ω Voice Coils = 2Ω Load
to amp
to amp
to amp
