Kicker Hideaway HS8 User Manual

2
Hideaway™
POWERED SUBWOOFER
ENCLOSURE Owner’s Manual
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER powered subwoofer enclosure. Carefully
check the areas where the mounting straps will be placed. Make sure the mounting screws will not puncture
the gas tank/brake lines/wiring or interfere with any mechanical parts on the underside of the mounting surface.
Choose a location that allows at least 4” (10cm) of open ventilation for the amplifi er. If possible, mount the
enclosure in the climate-controlled passenger compartment.
Authorized KICKER Dealer:
Purchase Date:
Model Number:
Serial Number:
Model: HS8
Subwoofer | inches [cm] 8” [20]
RMS power @14.4V | ≤ 1% THD+N [10% THD+N] 125W [150W]
Frequency Response 25Hz–120Hz
Crossover 12dB/octave Lowpass 50–120Hz;
24dB/octave Highpass @ 25Hz
Phase Switch 0° / 180°
Input Sensitivity Low Level: 125mV–5V
High Level: 250mV–10V
KickEQ bass boost Variable to +6dB @ 40Hz
Remote bass Included
Net weight | lbs. [kg] 11.4 [5.2]
Height | inches [mm] 3 1/8” [79]
Width | inches [mm] 9 3/8” [238]
Depth | inches [mm] 13 7/8” [352]
MODEL: HS8
The ultra-compact KICKER Hideaway™ Enclosure offers the quickest and easiest way to add a subwoofer to
your vehicle, providing signature KICKER bass in an unprecedentedly small enclosure. This system has been
meticulously fi ne-tuned by KICKER engineers to deliver astounding performance and sound without the time-
consuming setup required for a typical amp-sub upgrade.
2011 Hideaway Rev N.indd 22011 Hideaway Rev N.indd 2 5/30/2017 1:55:35 PM5/30/2017 1:55:35 PM

Kicker Hideaway HS8 Specifications

General

Brand	Kicker
Model	Hideaway HS8
Category	Enclosure
Language	English
