3
plastic mounting inserts
plastic mounting inserts
supported diameters:
1.625” [42.3mm]
1.75” [44.4mm]
1.875 [47.6mm]
2” [50.8mm]
2.25” [57.2mm]
2.375” [60.3mm]
2.5” [63.5mm]
stainless steel socket-
head cap screws
(1/4” Allen wrench)
stainless steel socket-
head cap screws
(1/4” Allen wrench)
place mounting
inserts
place remaining
mounting inserts
place and screw
the mounting
bracket bottom
to the top of the
KMT67 enclosure
place and screw
the mounting
bracket top to
the mounting
bracket bottom
mounting bracket bottom
mounting bracket top
mounting
bracket top
1
2
3
4
