Kicker L5 - Page 13

C
S12L5 Compact Enclosure Response Curve
S12L5 Street Bass Response Curve
S12L5 SPL/Deep Bass Enclosure Response Curve
10 Frequency Hz 20 30 40 50 60 70 80 100
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
95
90
85
80
75
70
65
60
55
C
S15L5 Compact Enclosure Response Curve
S15L5 Street Bass Response Curve
S15L5 SPL/Deep Bass Enclosure Response Curve
10 Frequency Hz 20 30 40 50 60 70 80 100
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
95
90
85
80
75
70
65
60
55
Vented Box Response Curves
S15L5 3.0cu.ft./4.5cu.ft./6.0cu.ft.
S12L5 1.75cu.ft./2.5cu.ft./3.25cu.ft.
Kicker Solo-Baric L5-Series Subwoofers
Recommended Applications
Page 13
