Kicker L5 Technical Manual

C
S8L5 Compact Enclosure Response Curve
S8L5 Street Bass Response Curve
S8L5 SPL/Deep Bass Enclosure Response Curve
10 Frequency Hz 20 30 40 50 60 70 80 100
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
90
85
80
75
70
65
60
55
50
C
S10L5 Compact Enclosure Response Curve
S10L5 Street Bass Response Curve
S10L5 SPL/Deep Bass Enclosure Response Curve
10 Frequency Hz 20 30 40 50 60 70 80 100
C
Graph 1 > Acoustic On Axis Response: SPL, Phase dB
95
90
85
80
75
70
65
60
55
Kicker Solo-Baric L5-Series Subwoofers
Recommended Applications
Page 12
S8L5 .66cu.ft./.80cu.ft./1.0cu.ft.
Vented Box Response Curves
S10L5 1.25cu.ft./1.75cu.ft./2.25cu.ft.

Kicker L5 Specifications

General

Enclosure Recommendation	Sealed or Vented
Size	12 inches
Impedance	2 ohms or 4 ohms
Min Sealed Box Volume	1.0 cu. ft (12")
Min Vented Box Volume	1.75 cu. ft (12")
Frequency Response	25-500 Hz
Voice Coil	2.5 inches
Mounting Cutout	11.125 inches
