Kidde Fire Systems FM-200 ECS Series User Manual

4-11
September 2004 90-FM200M-000
FM-200
®
ECS Series Engineered Fire Suppression Systems
156
5
43
2
1
SLAVE
CYLINDER
(TYP.)
DISCHARGE
HOSE OR
VALVE
OUTLET
ADAPTER
PRESSURE TRIP
P/N 874290
TEE (TYP.)
P/N 6992-0505
ACTUATION
HOSE (TYP.)
P/N 264986 OR
264987
PIPING
90° ELBOW
P/N 6992-0503
PRESSURE
OPERATED
CONTROL HEAD
(TYP.) P/N 878737
MASTER
CYLINDER
MASTER
CONTROL
HEAD
PRESSURE
SWITCH
P/N 486536
Figure 4-5. Pressure Actuation Using Pressure from 1 Master FM-200 Cylinder to Actuate
a Maximum of 15 FM-200 Cylinders Close Coupled
MASTER
CYLINDER
SLAVE
CYLINDER
SLAVE
CYLINDER
MASTER
CONTROL
HEAD
100 FT. MAX.
LENGTH OF TUBING
5/16” O.D. x .032 WALL
COPPER TUBING
MASTER CYLINDER
ADAPTER KIT P/N
844895 ATTACHED TO
SLAVE ACTUATION PORT
TEE P/N 6992-0505
1
4
DISCHARGE HOSE
OR
VALVE OUTLET
ADAPTER
PIPING
PRESSURE TRIP (TYP)
P/N 874290
(IF REQUIRED)
PRESSURE SWITCH (TYP.)
P/N 486536
90° ELBOW
P/N 6992-0503
PRESSURE OPERATED
CONTROL HEAD (TYP)
P/N 878737
Figure 4-6. Pressure Actuation Using Pressure from 1 Master FM-200 Cylinder to Actuate
a Maximum of 4 FM-200 Cylinders NOT Close Coupled
MASTER
CYLINDER
SLAVE
CYLINDER
SLAVE
CYLINDER
SLAVE
CYLINDER
MASTER
CONTROL
HEAD
220 FT. MAX
LENGTH OF TUBING
100 FT. NOMINAL
LENGTH OF TUBING
320 FT. TOTAL
MAX. LENGTH OF TUBING
5/16” O.D. x
.032 WALL
STAINLESS
STEEL
TUBING
TEE P/N
6992-0505
2
1
15
DISCHARGE
HOSE OR
VALVE OUTLET
ADAPTER
PRESSURE OPERATED
CONTROL HEAD (TYP)
P/N 878737
90° ELBOW
P/N 6992-0503
PRESSURE SWITCH (TYP.)
P/N 486536
PRESSURE TRIP (TYP)
P/N 874290
(IF REQUIRED)
PIPING
PILOT N
CYLINDER
P/N 877940
2
MALE
CONNECTOR
P/N 6992-0501
Figure 4-7. Pressure Actuation Using Pressure from 1 Nitrogen Pilot Cylinder to Actuate
a Maximum of 15 FM-200 Cylinders NOT Closed Coupled
