Kidde I9060

3. Installation Instructions
FIGURE 5
FIGURE 5A
AA
FIGURE 6
FIGURE 6A
FIGURE 7
FIGURE 7A
FIGURE 8
FIGURE 9
i9030 mounting
bracket shown
mounting
bracket for all
other models
5º
When wall mounting,
mount flat side to the
wall and rotate mount-
ing plate approximately
5º to the right as shown.
The “A” line should be hori-
zontal and the “UP FOR
WALL MOUNTING” arrow
must be pointing up.
Alignment marks
Install
Remove
