Kidde KN-COPP-3 User Manual

Installation
10
This alarm has an adaptor that allows you to install the
alarm as a wall mounted unit, as a direct plug unit, or as a
tabletop unit.
Direct Plug
In its “as shipped” configuration, the unit is ready to be
plugged directly into a wall socket.
To install:
• Choose a standard, unswitched 120 V outlet to plug
alarm into.
• Pull the slide support out approximately 6 mm (1/4")
until slide snaps in place (this will help support unit in
wall outlet).
• Plug the alarm into an electrical outlet.
Mounted horizontally (sideways):
If you are going to use your alarm as a direct plug and you
are going to plug in to an outlet that is mounted
horizontally (sideways), you will need to rotate the
adaptor 90˚. To rotate the adaptor:
• With back of unit facing you (adaptor at the top), place
your thumbs on the thumb grips.
• With your thumbs, push down in the direction of the
arrows on the thumb grips and slide back door off.
Back of unit when
used as direct plug.
Back of unit when
used as direct plug
for sideways outlet.
Back of
unit when
used as a wall mount.

Kidde KN-COPP-3 Specifications

General

Model	KN-COPP-3
Category	Carbon Monoxide Alarm
Power Source	AC Plug-In
Sensor Type	Electrochemical
Test/Reset Button	Yes
Battery Backup	Yes
Audible Alarm	85 dB at 10 feet
Low Battery Signal	Yes
Certifications	UL Listed
Display	Digital
Alarm Type	Audible
Operating Temperature	40°F to 100°F (4°C to 38°C)
Operating Humidity	10% to 95% relative humidity (non-condensing)
Weight	0.5 lbs
Warranty	5-year limited warranty
