Kidde VM-1 Technical Reference Manual

Appendix B: Addresses
190 P/N 3101890-EN • REV 006 • ISS 21JUN18
Address formats
VM-1 addresses are in PPCCDDDD format, where:
• PP is the cabinet number. Possible values are 01 (single panel systems) or 01 to 08 (networked systems).
• CC is the card number. Possible values are listed in Table 76.
• DDDD is the device number. Possible values are listed in Table 77, Table 78, and Table 79.
Card numbering
Cards have a physical address and a logical address. The physical address identifies the card’s location in the
panel. The logical address identifies the card in the CPU database. See Table 76 and Figure 57 on page 191.
Table 76: VM-1 card numbering
VM-PMI and
VM-MFK
VM-PMI
only
AMK-RN
only
Card or circuit
Logical addresses
VM
-CPU Main Board 00 00 00
VM
-LCD User Interface 00 00 00
PS10
-4B Power Supply 02 02 02
L
oop controller on the VM-CPU 03 03 03
Display modules
35 35 35
VM
-DACT Dual Line Dialer Card [1] 05 05 05
VM
-SLCXB Signaling Line Loop Controller Expansion Card [1] 05 05 05
Remote annunciator interface
04 04 04
VM
-PMI Paging Microphone Interface 06 06 N/A
VM
-MFK Firefighters Telephone 07 N/A N/A
1st ACHS card [2]
08 07 06
2nd ACHS card [2]
09 08 07
3rd ACHS card [2]
10 09 08
[1] Either a VM
-DACT card or a VM-SLCXB module can be installed in the slot.
[2] ACHS card logical address values vary depending on
whether the VM-PMI and VM-MFK are installed. The
AMK-RN does not have a logical address.
