ENG
9
Press down the locking device (a) on the
shoulder support frame (d).
Close the back cover again.
Note that the frame is completely locked in place in the rest
part.
4.2.2 Setting the seat surface length (thigh rest)
Bigger children will have significantly more seating comfort by pulling out the
seat ramp (fig. 7). Under the seat ramp there are three ramp settings in the
seat.
1. Tilt the seat ramp (e) approx. 3 – 5 cm
upwards and pull forwards.
The seat ramp can break where there is
too much pressure! The seat ramp should
not be removed.
2. Once you have your required seat length,
press ramp (e) into the appropriate snap-on
device. There are three positions possible.
Fig. 6
Fig. 7
a
d
e
