KidTrax Fire Engine KT1003 - Attach Rear Wheels

7
Assemble the Fire Engine
1. Locate a wheel marked
“REAR” on the inside.
Slide a wheel onto
the axle. Fit the wheel
into the gear box.
NOTE: For the rear
wheels, a large washer
is NOT needed before
sliding a wheel
onto the axle.
Then slide a hubcap
onto the axle, fitting
the three locating pins
into the holes.
2. Slide a small washer
onto the axle.
Attach a nut onto the
axle and tighten snugly
with the nut wrench
until you can see about
two threads
on the axle. Do not
overtighten.
Attach Rear Wheels
1
3. Then slide a wheel cover
over the nut, fitting the
three locating pins into
the holes.
Repeat steps 1 - 3
to attach the other
rear wheel.
2
2a
3
