PLZ2004WB General Information 1-1
Chapter 1 General Information
This chapter gives an overview and describes the features of the PLZ2004WB.
About This Manual
This operation manual describes the PLZ2004WB Load Booster.
The PLZ2004WB is used in combination with the PLZ1004W Electronic Load.
This manual mainly covers the handling precautions of the PLZ2004WB and the
connection to the PLZ1004W. For the operating procedure as a electronic load, see
the PLZ1004W Operation Manual.
Product Overview
The PLZ2004WB Load Booster is used to increase the input current to the
PLZ1004W Electronic Load. One PLZ1004W is made the master unit, and load
boosters connected in parallel operate as slave units.
Features
• Up to four load boosters can be connected in parallel with a PLZ1004W master
unit, configuring a electronic load that produces up to 9 kW and 1
800 A.
• The master unit displays the total current and total wattage. The units connected
in parallel can be used as a single electronic load.
• The connection of the control cables is easy. The control cable used to connect
between the master unit and the load booster and between each load booster is
one flat cable each.
• There is no power switch. The AC input power is turned ON/OFF by the master
unit.
Options
Control flat cables
Control cable used to connect between the master unit and the load booster and
between load boosters. The following two types of cables are available.
The two types of cables only differ in their length. The 550-mm PC02-PLZ-4W is
required to connect the master unit and the load booster.
Model Code Length Application
PC01-PLZ-4W 84540 300 mm Connect between load boosters
PC02-PLZ-4W 84550 550 mm Connect between the master unit and load booster
