Access CAL submenus
Leave CAL submenus
Enter the LO menu and save the LO Weight values for each Axle.
Press the Enter button for 2 seconds to enter the Kimax 2 menu.
(PPP is showed)
Press the Scroll button some times until CAL is shown.
Press the Enter button to enter the calibration submenu.
(LO is shown)
Press the Enter button to enter the LO menu.
(The LO value for the first active axle is shown)
Change the value if needed using the -/+ button.
Press the Save button to save the LO value for the current axle.
Switch between the active axles using the Scroll button.
Repeat the last three steps, to set all the LO values.
When this is done press the Enter button to leave the LO menu.
(LO is shown)
Press the Scroll button some times until OFF is shown.
Press the Enter button to leave the calibration submenu.
(CAL is shown)
Press the Scroll button some times until OFF is shown.
Press the Enter button to leave the Kimax 2 menu.
Access menu
Save LO value
Leave menu
Ad
j
ust
Next active
axle
Save LO value
Ad
j
ust
LO value
First active axle
LO value
Active axle “n”
1 ≤ n ≤ 8
