Typical application:
SG sensor on front axle combined with air suspension on rear axles.
For information on how to install SG sensors on your vehicle please visit www.kimax.com
where an installation procedure will be available for download.
Kimax 2 Radio
SG 1 sensor
Air 1 right
Air 1 left
Air 1 right
Air 1 left
SG 1
