Kimberley KARAVAN 2021 - External Shower and Grey Water Tank; External Shower and Grey Water Management

62
©2021 Kimberley Kampers Manufacturing Pty Ltd
External Shower
The Karavan can be equipped with an external shower unit. This is located on the left hand side of the tailgate
section.
How to use the external shower:
1. Click connect the supplied shower hose to outlet
2. Turn on pumps inside Karavan at the dash control panel
3. Start Diesel hot water system if required
4. Lift the mixer tap to start water ow and twist to adjust temperature
Water System | Grey Water Tank
Your Karavan may be tted with a Grey water tank which can receive water from your shower and internal sink
systems. Grey water can be either diverted to this grey water tank or directly to the outside environment via an
outlet pipe.
1. To capture grey water turn the ow valve to the “CLOSED” position and leave outlet pipe attached to the
chassis rail upper position.
2. To expel grey water from tank, turn the ow valve to the OPEN position and place outlet pipe hanging down
from chassis rail.
NOTE:
Ensure valve is closed and outlet
pipe is attached in upper chassis rail
position when travelling.
