Kimpex CLICK N GO 2 - Mounting Instructions

MOUNTING INSTRUCTIONS
MOUNT PLATE FOR “CLICK N GO 2” SNOW PLOW FRAME
KIMPEX NO. 373951-8
Grizzly
KIMPEX INC. / 5355, rue St-Roch / Drummondville (Québec) Canada / J2B 6V4
KIMPEX USA / 100 Walnut Street / Champlain, New York / 12919
A-7815010-8 • Imprimé au Canada / Printed in Canada
1
R
e
f.
Description
Item no.
Qt
y
R
e
f.
Description
Item no.
Qt
y
01
M8
-
1.25 x 60 mm
carriage bolt
2
05
Flat bar
1
02
M8
-
1.25 x 25 mm
carriage bolt
4
06
Locking plate
4
03
M8
-
1.25
self
-
locking flange nut
14
07
U
-
bolt
4
04
Universal mount plate
1
Note: The following parts will not be used for your vehicle: two (2) U-bolts 07 and four (4) M8-1.25 self-locking flange
nuts 03.
Exploded view
02
05
03
04
06
03
02
01
07
01
06
03
03
07
02
02
07
