MODULAR SOCKET SYSTEMS
Computer / Video Computer / Video
Model Connection No.
Blind cover No. 7441-400
No. 7444-400
Mains switch (duplex inset) No. 7444-200
VGA (HD 15) Soldering No. 7441-401
Plug No. 7441-501
Soldering No. 7444-401
Plug No. 7444-501
DVI-I (24 + 5 pin) Soldering No. 7441-402
Plug No. 7441-502
Soldering No. 7444-402
Plug No. 7444-502
Video (Cinch) Soldering No. 7441-403
Plug No. 7441-503
Soldering No. 7444-403
Plug No. 7444-503
Plug to 1xBNC
No. 7441-535
S-Video (4-pin Mini DIN) Soldering No. 7441-404
Plug No. 7441-504
Soldering No. 7444-404
Plug No. 7444-504
Plug to 2xBNC
No. 7441-536
Video / S-Video Soldering No. 7441-405
Plug No. 7441-505
Soldering No. 7444-405
Plug No. 7444-505
Component-Video Soldering No. 7441-406
(3 x Cinch) Plug No. 7441-506
VGA to BNC5 Plug No. 7441-507
Plug No. 7444-507
Scart duplex inset Soldering No. 7441-408
Plug No. 7441-508
supplied with special
mounting frame
VGA-Active duplex inset Plug No. 7441-509
Plug No. 7444-509
with integrated
VGA-amplifier 1:1,
400 MHz,
Required depth: 40 mm,
external power supply
230 V/12 VDC
Audio
Model Connection No.
Audio L/R (Cinch) Soldering No. 7441-410
Plug No. 7441-510
Soldering
No. 7444-410
Plug
No. 7444-510
Audio jack Soldering No. 7441-411
(3.5 mm stereo) Plug No. 7441-511
Soldering
No. 7444-411
Plug
No. 7444-511
XLR 3-pin duplex inset Soldering (XLR f) No. 7441-412
Soldering (XLR f) No. 7444-412
Soldering (XLR m) No. 7441-416
Soldering (XLR m) No. 7444-416
Speakon 4-pin duplex inset Soldering No. 7441-413
Soldering No. 7444-413
Loudspeaker Clamps No. 7441-414
suitable for loudspeaker
cable or jack plug
up to 4mm
2
Toslink Audio Gender changer No. 7441-515
Model Connection No.
BNC - single Gender changer No. 7441-537
BNC - duplex Gender changer No. 7441-538
BNC - 5 connections Gender changer No. 7441-539
HDMI Plug No. 7441-540
Plug No. 7444-540
F plug, duplex, Gender changer No. 7441-541
for satellite receiver
