Subject to technical alterations, as well as to changes of the design and the colour
33
MODULAR SOCKET SYSTEMS
Model Connection No.
VGA / 3.5 mm jack Soldering No. 5840-2
Blind inset ø 6.3 mm / Sub-D / f Plug No. 5840-3
VGA / 3.5 mm jack / CAT 5
Soldering No. 5590-2
Blind inset ø 6.3 mm Plug No. 5590-3
VGA/S-Video/Video (Cinch)
Soldering No. 5574-2
Blind inset for Sub-D / f Plug No. 5574-3
VGA / 3.5 mm jack Plug No. 5586-3
USB to CAT 5 (USB 1.1)
(max. length of CAT 5 cable 45 m)
VGA / 3.5 mm jack Soldering No. 5567-2
Video/Audio (Stereo) Cinch Plug No. 5567-3
VGA / S-Video / Video (Cinch)
Soldering No. 5568-2
Audio (Stereo Cinch) Plug No. 5568-3
S-Video / Video (Cinch) Soldering No. 5841-2
2 x Audio (Stereo Cinch) Plug No. 5841-3
XLR 3pin Soldering No. 5566-2
Supplied without insets
Modules for underfloor installation
For Ackermann underfloor housings
The module holders replace the
casings GB2 and GB 3
Individual combination of insets
Installation kits for underfloor housings
Model No.
Module holder GB2 No. 7475-2
with space for 4 half insets No. 7444-xxx
Module holder GB3 No. 7475-3
with space for 6 half insets No. 7444-xxx
Model No.
19“ patch panel for insets 7441-xxx No. 7446-1
(54x54 mm), with space for 6 double insets or
12 half insets, 2 „size 2U“
19“ patch panel with 2 sockets 230V, No. 7446-10
mains switch and rear Schuko connection
for connecting socket rails, with additional space
for 3 double insets or 6 half insets
7444-xxx (50x50 mm), 2 „size 2U“
Modules for 19“ racks
Available in 2 versions:
Patch panel with mains switch
Patch panel for insets only
Integration of wiring in 19 racks
Individual combination of insets
Installation kits for existing Ackermann casings
Supplied with:
Module with socket and soldering connection or
f/f with ca. 20-30 cm cable and plug
Cover plate for GB2 / GB 3
Cable protection
Model No.
Ackermann casing GB 2 No. 5596
Ackermann casing GB 3 No. 5596-1
Modules for underfloor housings
