1.If you want to connect indoor monitor to multi-button outdoor station
Keep pressing on indoor monitor 3 seconds, when you hear a long
sound"di" , means change mode success.
2.If you want to connect indoor monitor to one call button outdoor station
Keep pressing on indoor monitor 3 seconds, when you hear a long
sound"ding-dong" , means change mode success.
3.How to use J1 & J2 jumper on backside of indoor monitor Master
Monitor Jumper
J1=ON for 1 monitor in Loop, OFF all other items.
Video Termination-IMPORTANT
J2=ON for Last monitor in Loop, OFF all the items.
st
MULTI-BUTTON OUTDOOR WITH MONITORS
Important
-4-
