Kingfisher FPHPC100 - Page 12

FPHPC100
Getting started...
GB
IE
12
Your product
7HFKQLFDOVSHFL¿FDWLRQV
General
> Rated voltage : 220 - 240 V~, 50 Hz
> Rated input : 1400 W
> Rated pressure : 70 bar (7 MPa)
> Max. allowable pressure : 100 bar (10 MPa)
> Max. inlet water pressure : 7 bar (0.7 MPa)
> 5DWHGÀRZ : 5.5 l/min
> 0D[LPXPUDWHGÀRZ : 7.2 l/min
> Rated temperature : < 50°C
> Gun kickback force at maximum
pressure
: < 20 N
> Protection class :
II
> Degree of protection : IPX5
> Weight : approx. 5.61 kg
> Dimensions : approx. 214 x 230 x 452 mm
High pressure hose
> Permissible pressure : 120 bar (12 MPa)
> Maximum temperature : 60 °C
> Length : 3 m
Water hose (not supplied)
> Quality : reinforced garden hose
> Diameter : min. ø 13 mm (½“)
> Max. length : 25 m
Sound level
> Sound pressure level L
pA
: 78 dB(A)
> Uncertainty K
pA
: 3 dB(A)
> Measured sound power level L
WA
: 90.19 dB(A)
> Uncertainty K
WA
: 3.1 dB(A)
> Guaranteed power level L
WA
(according
to 2000/14/EC amended by 2005)
: 93 dB(A)
Vibration level
> Hand arm vibration a
h
: <2.5 m/s² (2.3 m/s²)
The sound values have been determined according to noise test code given in
EN 60335-2-79, using the basic standards EN ISO 11203 and EN ISO 3744.
The sound intensity level for the operator may exceed 80 dB(A) and ear
protection measures are necessary.
