FPHPC100
Getting started...
GB
IE
14
Before you start
Assembly
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Do not connect the product to power supply before it is completely
assembled!
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
Holders
> Attach the hose holder (5) to the product (Fig. 1).
> Attach the accessory holder (9) to the product (Fig. 2).
5
9
Fig. 1 Fig. 2
Pressure hose
> Insert the connector of the pressure hose (3) to the hose connection port (2d).
Ensure it snaps in place (Fig. 3).
> Remove the cap (8a) from the water outlet (8).
> Screw the pressure hose (3) clockwise to the water outlet (8). Make sure the
connection is properly tightened (Fig.4).
14
14
