26
S-400 & S-500 SEEDERS
Ref. No. Part #
1 Spreader Disc W\Vanes 900004
2 Agitator 900138
3 Buffer Wheel 900005
4 Lower Agitator Kit 509000
5 LH Shutter Lever 900120
7 RH Lever Tie Rod 900123
Model # S-400-P & S-500
6 RH Shutter Lever 900122
8 LH Lever Tie Rod 900121
9 Shutters (1-Left & 1– Right) 509001
10 Gearbox 900110
11 20” PTO Shaft 147020
12 Distributor Vanes (PK of 4) 509002
13 S-500 Steel Hopper 900133
14 Seeder Frame 900135
15 S-400 Poly Hopper 900134
To Next Page
