TG-48-XB & TG-54-XBX SERIES TOP GEARBOX PARTS LIST
Ref. No. Part #
Model # TG-48-XB
2 Input Shaft 977002
3 Retaining Ring 30mm x 27.9 ID 977003
4 Bevel Pinion (13 Teeth) 977004
5 Bearing Cone (30305) 977005
6 Bearing Cup (30305) 977006
7 Bearing Cone (32007x) 977007
8 Bearing Cup (32007x) 977008
9 Retaining Ring 62mm X 66 OD 977009
10 Output Shaft 977010
11 Hub Cap 977011
12 Bearing (6307) 155007
13 Shim Pkg. (2) 1mm & (2) .5mm 502243
14 Bevel gear (19Teeth) 977012
15 Retaining Ring 34mm X 31.5 ID 977013
16 Seal Input (13997) 35 X 62 X 8 977014
17 Freeze Plug 977015
18 Spacer 45 X 36 X 12.4 977016
19 Spur Pinion (18 Teeth) 977017
20 Gasket 977018
21 Hex Cap Screw, Lockwasher(4-Pk) 505024
22 Pressure Relief Plug 1/2” - 14NPT 902007
23 Flange Plug 1/2” - 14NPT 977019
24 Shim, Input OD 60 X ID 50 977022
25 Flange Plug (M10 - 1.0) 977023
26 O-Ring(- 011) 977024
Part #
TG-54-XBX
977002
977003
977004
977005
977006
977007
977008
977009
977025
977026
155007
502243
977012
977013
977014
977015
977016
977017
977018
505024
902007
977019
977022
977023
977024
1 Housing 977001 977001
