2 V1.15
2. TECHNICAL DATA
1. SAFETY INFORMATION
Please read the user manual and safety instructions carefully before using the appliance.
• For 12V Lead Acid based and Lithium LiFePO4 Batteries recommended battery capacity (25A DCDC
Model - 80 - 250 Ah) (40A DCDC Model - 120 - 400 Ah). For other Lithium-Ion batteries refer to section
“Charging Voltage Limits” to confirm if charging Voltage is applicable.
• Suitable for unregulated solar panels 10-32 Volts, up to 300 Watts for 25 Amp model and 500 Watts for
40 Amp model.
• NOT for under bonnet installation
• Install AWAY from flammable fumes, external heat sources, liquids and protected from oil, grease,
combustible material, dust & weather
• Ensure good VENTILATION around the unit
• Isolate the vehicles power source before installation of DCDC Charger
• Not recommend to cut or damage Temperature Sensor or wire, this may damage the DCDC
Charger.
• Ensure the unit is well secured to the inside of the vehicle
• Fuses are NOT supplied
• WARNING: The unit may get hot during operation
• Required minimum air gap, 150mm around unit
SPECIFICATIONS TABLE
25A DCDC Model 40A DCDC Model
Max Charging Current 25 Amps 40 Amps
Recommended Battery Capacity 60 - 250 Ah 120 - 400 Ah
Vehicle Input Voltage 9 - 32 Volts
Solar Input Voltage 10-32 Volts
Solar Input Capacity 300 Watts 500 Watts
Recommended Fuse Size 30 Amps 50 Amps
Idle Current Draw Under 15 mA
Suitable Battery Types Lead Acid, AGM, Calcium, LiFePO4, GEL
IP Rating IP66
