3. LEDS & FAULTS INDICATIONS
3.1 LED CHARGE INDICATOR
Alternator / Solar LED Battery Type LED Charging Stage
Short flash GREEN Solid GREEN Bulk or Absorption
Long flash GREEN Solid GREEN Float
OPERATION MODES
25A and 40A Models
Vehicle Charging System Turn On Turn Off
12 Volt Standard Alternator Above 13.1 Volts Under 12.8 Volts
24 Volt Standard Alternator Above 26.2 Volts Under 25.6 Volts
12 Volt Smart Alternator Above 12.0 Volts Under 11.8 Volts
24 Volt Smart Alternator Above 24.0 Volts Under 23.6 Volts
Long Flash = 1s off, 2s on, 2s off
Short Flash = 0.5s off, 0.5s on, 0.5s, off
SOLID ON = light on continuously
