4. INSTALLATION INSTRUCTIONS
The following installation instructions refer to the fitting for the accessories and mounting the Tourer X RTT to
a vehicle roof rack. All mounting fasteners supplied should be used.
DO NOT LIFT THE RTT BY YOURSELF.
USE A TEAM OF PEOPLE OR A FORKLIFT.
STEP 1
Unfold the tent and remove all the supplied fittings. Close RTT.
STEP 2
Lift the RTT onto the vehicle roof rack. Position RTT to allow space for the lid
latches to be opened and closed.
STEP 3
Assemble bolts with mounting track adaptors. See image alongside.
STEP 4
Push track slides with bolts into the desired tracks on the underside of the RTT by
lifting the RTT to one side.
STEP 5
Ensure that the mounting bolts are aligned around the roof rack structural cross
bars. (Use all 4 supplied mounting plates.)
STEP 6
When satisfied with the position of the RTT, place the mounting plates over the bolts
and screw on the nyloc nuts. Tighten the nyloc nuts and ensure that the bolt thread
has fully come through the nyloc nut. See image alongside.
STEP 7
Regularly check the RTT bolted connections are secure. Tighten if necessary.
