ID Part name QTY Part # model S (12”)
24871516
Part # model M (18”)
24787181
A
Bolt (18”/21”/24”)
16 5131850
B
Screwdriver (18”/21”/24”)
1 5131851
1
Support bracket (18”/21”/24”)
4 5131852
2
Locking caster wheel (18”/21”/24”)
2 5131853
3
Caster wheel (18”/21”/24”)
2 5131854
4
Bracket crosspiece (18”/21”/24”)
2 5131855
5
Main cooking grid
1 5131656 5131856
6
Charcoal plate
1 5131657 5131857
7
Firebox
1 5131658 5131858
8
Ceramic body
1
Lid: 5131659
Base: 5131660
Lid ring: 5131661
Base ring: 5131662
Bolt: 5131663
Washer: 5131664
Locking washer: 5131665
Nut: 5131666
Lid : 5131859
Base : 5131860
Lid ring: 5131861
Base ring: 5131862
Bolt: 5131863
Washer: 5131864
Locking washer: 5131865
Nut : 5131866
9
Top damper vent
1
5131667 5131867
10
Lid handle
1
Brackets: 5131668
Handle: 5131669
Brackets: 5131868
Handle: 5131869
11
Side shelf
2 5131670 5131870
12
Side shelf brackets
4
left: 5131671
right: 5131672
left: 5131871
right: 5131872
