Kingstone S (12”) - Page 31

31
ID Part # model L (21”)
24790134
Part # model XL (24”)
25585926
Part image
A 5132150 5132450
B 5132151 5132451
1 5132152 5132452
2 5132153 5132453
3 5132154 5132454
4 5132155 5132455
5 5132156 5132456
6 5132157 5132457
7 5132158 5132458
8
Lid: 5132159
Base : 5132160
Lid ring: 5132161
Base ring: 5132162
Bolt: 5132163
Washer: 5132164
Locking washer: 5132165
Nut: 5132166
Lid: 5132459
Base : 5132460
Lid ring: 5132461
Base ring: 5132462
Bolt: 5132463
Washer: 5132464
Locking washer: 5132465
Nut: 5132466
9
5132167 5132467
10
Brackets: 5132168
Handle: 5132169
Brackets: 5132468
Handle: 5132469
11 5132170 5132470
12
left: 5132171
right: 5132172
left: 5132471
right: 5132472
