KINKI STUDIO
4
CONNETIONS
連接
5
<+ 7%""4( #)%" =
Connect the power cord to the IEC inlet of the amplifier and plug it into the power plug socket.
For safety reasons, a 3-wire grounding (earth) plug must be used, whenever possible.
In order to get the best sound from the amplifier, avoid using any multiple plugs socket or
extension cords.
The signal input connections are located at the rear panel with indication.
You may use either RCA or XLR connection to source/preamp. The XLR Pinout is as follow:
- Pin 1 (Shield)
- Pin 2 (Hot)
- Pin 3 (Cold)
Warning: Do not remove/insert the interconnects and speaker cable when the amplifier is
powered on. Always remember to unplug the power cord before any connection of cables
2 HOT
3 COLD
1 SHIELD
