Kinroad XT50Q - Throttle Cable and Carburetor Adjustment

18
Adjustmen
t
o
f
Throttle Cable
Make sure that the adjust ing nut of the throttle
cable and locking nut work normally.
Check to see if the throttle twist grip is with the
required free operating movement.
The required free operating movement:2-6mm.
If the grip can not be so moved freely.turn the
adjust ing nut to ensure it.
After adjustment, start the engine and check for
the free operating movenent again,Repeat the
adjustment if necessary until it is as required.
Adjustmen
t
o
f
Carburetor
Caution:
The adjust ing procedures of idling speed:
1.Support the vehicle by a stand.
2.Adjust the idling speed by the throttle stop
screw(1) to 1500f150rpm.
Caution:
Do not try to cover up any trouble of other parts of the
carburetor by adjust ing the idling speed. In case of
any abnormality with the carburetor,it has to removed
by your dealer.
Adjust ment of idling speed shall be made only when
the cold engine is warmed up or 10 minutes after the
motorcycle is stopped from driving.
