Tolerances:
Unless otherwise
specified
X.X =
1/16"
Angular =
1.0
Drawn By:
Checked By:
Size:
File Name:
Units:
Date:
Date:
Req'd:
Description:
Tektite Manufacturing Inc.
427 Buffalo Street, Winkler MB, R6W 4A8, Canada
CNC:
Index Service Part # File Name
Description
Qty
1 A00-0013 TEKT-0009 5MM Bushing 5
2 A00-0014 TEKT-0092 Thick Bushing 3
3 A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB 1
4 A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB 3
5 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD 4
6 A00-0033 315-080 Rear Wiper Shaft Grommet 1
7 A00-0043 WWF-MOTOR WWF Wiper Motor, 1" Shaft 1
8 A00-0108 TEKT-ASM-037 WWF, Adjustable Radial Arm, 15" to 19" 1
9 A00-0339 NAPA_6-1565 Deluxe 16" WWF 1
10 M06-0002 MFGC1725M-106 Rear Window Glass 1
11 M06-0006 MFGC1725M-113- Rear Window Seal 1
1 req Rear Window Assembly
Daryl Furkalo
2019-06-03 Imp.
MFGC1725M-ASM-17_OP
B
M06-0024
SCALE 0.250
1
2
3
4
5
6
7
8
9
10
11
