5-4 DK6511/751/801/901
C86O502A
2. Push the PTO switch to the off position.
C86O503A
3. Place the main shift lever and the P.T.
O clutch lever in the neutral position.
(1) Main Shift Lever (2) P.T.O Change Lever
(1) PTO Switch
(A)
- OFF (B) - ON
DK651 DK751/801/901
C86O504A
4. Lower the implement if attached by
pushing the position control lever
forward.
(1) Position Control Lever
DK751/801/901
DK651
