OPERATION 5-9
4. Pull the position control lever backward
to raise the implement, if attached.
C86O510A
(1) Position Control Lever
5. Increase the engine speed slowly from
idle speed to about half throttle.
6. Fully depress the clutch
C86O511A
(1) Hand Accelerator Lever
DK751/801/901
DK651
DK751/801/901
DK651
7. Release the parking brake.
8. Using the main shift lever, the Hi-Lo
shifter, and the forward/reverse
shuttle lever; select the desired direc-
tion of travel and the speed range.
9. Release the clutch slowly until the trac-
tor begins to move.
C86O512A
(1) Parking Brake Lever
CAUTION
Interlock the right and left brake
pedals before starting. Uneven
braking may result in loss of con-
trol or rollover.
Do not allow any person other
than the driver to ride on the
tractor.
DK651 DK751/801/901
To Next Page
