10
-8 EX35/40/45/50
INITIAL 50 HOURS
CHANGING ENGINE OIL
1. To drain the used oil, remove the
drain plug at the bottom of the en-
gine and drain the oil completely into
the oil pan.
All the used oil can be drained out
easily when the engine is still warm.
2. After draining reinstall the drain plug.
3. Fill with the new oil up to the upper
notch on the dipstick.
(1) Oil Inlet (2) Dipstick
(A) Oil level is acceptable within this range
(1) Drain Plug
To avoid personal injury:
Be sure to stop the engine be-
fore changing the oil.
Allow engine to cool down
sufficiently, oil can be hot and
can burn.
!!
!!
!
CAUTION
T46OA09A T46OA10A
(1) Engine Oil Filter
REPLACING ENGINE OIL
FILTER
To prevent serious damage to
the engine, use only a KIOTI
genuine filter.
T46OA11A
IMPORTANT
Oil
capacity
with filter
5.5 (1.5U.S.gals.)EX35
EX40
EX45/50
8.0 (2.1U.S.gals.)
To Next Page
