K9 2400
K9 2440
1. PACKING LIST & ACTUAL IMAGE
NO. Part No. Description
Q'TY
Remark
KIT 1 KIT 2
1 01123-50816 BOLT, WASHER 4 4
2 01123-50845 BOLT, WASHER 2 2
3 02763-50080B NUT, FLANGE (BLACK) 13 13
4 03016-50830 SCREW 2 2
5 03016-50840 SCREW 2 2
6 04613-50040 SNAP RING 2 2
7 C7210-38511 HEAD SCREW , THRUST 5 5
8 C7280-89211 BRACKET, WASHER TANK 1 1
9 01754-50720B BOLT, FLANGE (BLACK) 8 8
10 T4145-83711 COLLAR (RESIN) 4 4
11 T4145-83721 CAP 4 4
12 T4340-87181 ASSY, WASHER LIQUID TANK 1 1
13 T4520-87402 PACKING, 1 2 2
14 T4620-81842 BOLT, CUSHION 2 2
15 01754-50616B BOLT, FLANGE 5 5
16 T4815-82431 BRUSH, WINDOW - 16 INCH 1 1
17 T4815-89171 GROMMET 1 1
18 T4815-93211 CAP NUT, M8 6 6
19 T4930-83701 HEAD PIN, SIDE MIRROR 2 2
20 T4930-83721 CUSHION, A 4 4
21 T4930-83731 CUSHION, B 4 4
22 T4930-85081 GRIP, SIDE - LH 1 1
23 T4930-85091 GRIP, SIDE - RH 1 1
24 T5270-69913 WIPER MOTOR - FR 1 1
25 T5525-80331 HARNESS WIRE JABARA, WORK LAMP 2 2
26 T5710-69971 MICRO RELAY, 5P 1 1
27 U3210-97221 BRACKET ASSY,FRONT WIPER MOTOR 1 1
28 U3210-97251 COVER, FRONT WIPER MOTOR 1 1
29 U3215-97161 SCREW 2 2
30 UD26-0017B ASSY WIRE HARNESS, CONNECTING WIPER 1 1
31 UD26-0036A SWITCH, WIPER - FR LED 1 1
32 UD27-0022A GARNISH CLIP 7 7 EXTRA PARTS
33 UD28-5966A FRAME STAY - UPR 4 4
34 UD28-5968A COVER, WIRE HARNESS 1 1
35 UD28-5975A COVER, LOWER 1 1
36 UD28-5976A WEATHER STRIP, LOWER COVER 1 1
37 UD28-5977A HOSE, WASHER LIQUID 1 1
38 UD28-5982A SPRING HINGE 2 2
39 UD28-5986A BRACKET, WASHER TANK 1 1
40 UD28-5992A HOLE CUTTER 1 1
41 UD28-5993A ARM, WIPER (M8 x 320) 1 1
42 UD28-59BJB FRAME UPR ASSY 1 1
43 UD28-59BLB FRAME LWR ASSY 1 1
44
KIT 1 UD28-59CCA TEMPERED GLASS SUB-ASS'Y 1 -
KIT 2 UD28-59CDA LAMINATED GLASS SUB-ASS'Y - 1
45 T2198-82551 BAND CABLE 3 3
