13-2 KL 120
GENERAL INFORMATION
Illustrations
All parts are illustrated in "exploded views" which show the individual parts in their normal reationship to eash other.
Reference numbers are used in the illustrations. These numbers correspond to those in the "Reference Number".
column and are followed by the quantity required and description.
Directional Reference
"Right hand" and "left hand" sides are determined by standing at the rear of the unit and facing in the direction of forward
travel.
Parts Order
Orders must give the complete description, correct part number, the total amount required, the product model,
all the necessary serial numbers, the method of shipment and the shipping address.
Instructions
1. GROUP NAME
: Detail classiflcation name for parts.
2. SECTION NAME
: Classiflcation name for parts.
3. COMPONENTS
: The components of an assembly are identifled by a bracket.
4. NO.
: Reference numbers are assigned to parts in the figure.
