9
4.1(c) Insert the engine key and turn the engine switch to ON position.
4.1(d) Electric Start: turn the engine switch to the START until the engine has started. Do not operate
the starter for more than 10 seconds.
Manual Start: pull the starter grip lightly until resistance is felt then pull the starter grip briskly
toward the arrow as shown below.
■Do not allow the starter grip to snap back. Return it slowly by hand.
■Do not let the starter rope rub against the generator body or the rope
will wear out prematurely.
Engine switch
Fig.8
Fig.9(a)
Fig.9(b)
Engine switch
Starter grip
