Kipor KDE13SS3 User Manual

51
Model KDE75SS3 KDE100SS3
Rated frequency Hz 50 60 50 60
KVA 62 75 75 100
Rated output
KW 49.6 60 60 80
Rated voltage V 230/400 240/416 230/400 240/416
Rated current A 89.5 104 115 138.8
Rated rotation speed r/min 1500 1800 1500 1800
Phase no./ Excitation mode
Three phase /
Brushless self-excitation and constant voltage (with AVR)
Power factor (cosφ) 0.8(lag)
Insulation grade H
Generator
Pole number 4
Model KD6105G KD6105ZG
Type
Four cylinder, 4-stroke, direct
injection
Four cylinder, 4-stroke, direct
injection
Cylinder No.-Bore × Stroke mm 6-105×125 6-105×125
Displacement L 6.494 6.494
Compression ratio
17.5:1
Rated power KW（r/min） 59/1500 70/1800 72/1500 85.5/1800
Fuel type 0# (summer), -10# (winter), -35# (cold) light diesel
Lube oil type
Above CD grade, SAE 10W30 or 15W40
Fuel consumption g/kw·h
≤290 ≤280
Fuel tank capacity L 110 110
Engine
Continuous running time h 6 5 5 4
Overall dimension LXWXH
mm 2700×1150×1500
Net weight kg 1650 1680
Starting mode 12V electric starting
Noise at zero load dB(A)/1m 68 70 68 70
Noise at rated load dB(A)/7m 51 53 51 53
Set
Structure type
Ultra silent
