KIRLOSKAR Non-Clog Submersible Series User Manual

5
This is a proprietary document of Kirloskar Brothers Limited,
YAMUNA’ Survey No. 98/ 3 to 7, Baner, Pune
–
411045, India.
NS IOM MANUAL
1
Sept
2018
1. GENERAL :
1.1 KIRLOSKAR submersible sewage pumps type “NS” is available in the following types.
1. iNS series (1HS Series Code)
Unit kW Ratings in 2Pole kW Ratings in 4Pole kW Ratings in 6Pole
iNS unit - 1 0.75-1.1 0.55-0.75 -
iNS unit - 2 1.5-2.2 1.1-1.5 -
iNS unit - 3 3.7 2.2 -
iNS unit - 4 5.5-7.5 3.7-7.5 2.2-5.5
iNS unit - 5 9.3-18.5 9.3-15 -
iNS unit - 6 22 18.5-22 -
2. NS Series (192 Series Code)
Unit kW Ratings in 4Pole kW Ratings in 6Pole
NS unit - 1 - 7.5 -11
NS unit - 2 - 15
NS unit - 3 30 18.5-22
NS unit - 4 37-45
30
NS unit - 5 55 37
NS unit - 6 75 45
NS unit - 7 90 55
NS unit - 8 110-132
75-110
NS unit - 9 160-200
132-180
NS unit - 10 225
-
The following charts can be referred to know the pumps available in type of impellers ratings.
A. Refer below chart for 2 pole Models: (iNS)
*-design
developed. #-yet to develop.
How to read – NS20/13QT 1.1/2 i (i-stands for iNS)
Sr.
No.
IMPELLER kW RATING IN 2 POLE
PUMP QT 0.75 1.1 1.5 2.2 3.7 5.5 7.5 9.3 11 15 18.5 22
1 20/13
*
*
*
*
*
2 20/16
*
#
*
*
*
3 20/20
*
*
*
*
*
*
*
4 32/13
*
*
*
*
5 32/16
*
*
*
*
6 40/13
*
*
*
*
7 40/16
*
*
*
*
8 40/20
*
*
*
*
9 50/13
*
*
*
*
10 50/16
*
*
*
*
*
*
*
11 50/20
*
*
*
*
*
*
12 65/13
*
*
*
*
*
*
13 65/16
* * * * * *
