Specification
1. Specification
Design and all specifications are subject to change without notice.
Product Name KiSS Coolview
LCD Type a-Si TFT-LCD
Screen Size 17” Wide (diagonal length)
Pixel Pitch 0.291mm x 0.291mm
Contrast Ratio 400 : 1(Typ.)
Luminance 450 cd/m
2
Active Display Area 372.48 mm (H) x 223.49 mm (V)
Viewing Angle L/R:75°/75°, U/D:50°/ 70°
Interface LVDS
TV receiving channels
VHF:Channels 2~13 UHF:Channels 14~69
Cable : Channels 1, 14~125
TV broadcasting system
NTSC-M mode
Audio Output Max. 5W x 2 / Stereo
PC Monitor Horizontal Frequency 30 ~ 61 kHz
Vertical Frequency 56~ 85 Hz
Colors 16.2M colors (6bit + FRC 2bit)
Maximum Resolution WXGA : 1280(H) x 768(V)
Other Resolution XGA, SVGA, VGA
Power Supply Adapter Input AC 100V~240V, 50~60Hz
Output DC 12V
Power Consumption Maximum < 40W
Power Saving/OFF < 5W
Power Saving Mode VESA DPMS
The present home appliance is certified and approved by EMC/EMI and can be used in all places
including residency area.
