FREEZER DOOR AND BASKET PARTS
14
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
1 2257798 Freezer Door
Panel (Includes
Item 9)
2 2317101 Divider,
Basket (2)
3 2314024 Mat, Basket
4
W10001170 Screw, 5/16 x 1
5
W10001160 Screw
6 2309219 Filler, Foam
7 2316788 Spacer, Door
Edge − Side
8 2309221 Spacer, Door Edge
Top & Bottom
9 2309216 Door Gasket,
Magnetic
10 308544 Screw, 10−24 x 1/2
11 2005290 Handle, Door
12 2309127 Skin, Door
13 8281250 Screw, 8−15 x 1/2
14 2309401 Basket Assembly,
Freezer
15 2207454 Nut, Hex
16
W10001190 Washer
17
W10001180 Screw, 10−24 x 1/2
(Basket to Slide)
