CABINET PARTS
2
For Model: KBFC42FSS00
(Stainless Steel)
W10044170
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2317821 Use & Care Guide
2309317 Energy Label
2316852 Service & Wiring
Sheet
2317849 Main Control
Service Sheet
2317840 Modular Icemaker
Service Sheet
2309309 Installation
Instructions
2 Cabinet (Not A
Serviceable Part)
3 2005004 Grommet, Crossover
Tube
4 1112023 Roller,
Front & Rear (4)
5 Support, Leveler
Assembly
2004506 Refrigerator Side
2004505 Freezer Side
6 2005006 Grommet, Wiring
7 2005007 Grommet, Flexible
8 8281164 Screw
9 2006442 Mounting Bracket,
Grill
10
W10004850
Screw
11
W10004860
Screw
12 2004514 Clamp
13 2314064 Tube, Drain
14 2207470 Shim−Hinge, Door
15 487415 Screw, 8−18 x 3/8
16 2208136 Clamp, Tube
17
W10005070
Screw, Door Stop
18 2316759 Hinge, Door
Refrigerator Top
19 2316860 Cam−Closer,
Door
20 2221070 Clamp, Tube
21 2006617 Bracket,
Support Door
22 2316758 Stop, Door
23 2209022 Housing,
Water Filter
24 2221242 Spring,
Door Closure
25 486194 Screw
26 2255709 Filter, Water
27 2316859 Bushing−Arm,
Extension
28 2004994 Bushing, Hinge (2)
(Lock−Adjustable)
29 2302889 Hinge, Bottom
Refrigerator Door
30 489464 Screw, 8−18 x 1/2
31 489282 Screw
32 2209025B Skirt, Grille
(Bottom)
33 2314023 Bushing, Hinge (2)
34 2316607B Grille Base,
Front
35 2215612 Cover, Air Duct
36 Arm, Extension
2266882 Right
2266881 Left
37 Bracket, Switch
2221097 Right
2221096 Left
38 2215938 Cover, Switch
39 2186494B Cap, Water Filter
40 8533913 Screw
41 1118894 Switch,
Rocker Arm (2)
42
W10005050
Screw, 8−18 x 1/2
To Next Page
